MINI NVR 8/16CH New 2017 Onvif P2P Cloud 960P/ 1080P mini 16CH NVR High Performance CCTV IP Camera Recorder 9Ch 3MP& 4Ch 5MP

92 % of buyers enjoyed this product!
Availability: in stock
Price:  US $55.00 / piece
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Share:

MINI NVR 16CH New 2017 Onvif P2P Cloud 960P/ 1080P mini 16CH NVR High Performance CCTV IP Camera Recorder 9Ch 3MP& 4Ch 5MP

MINI NVR 16CH 1080P/9CH 3MP/4CH 5MP 1HDD PORT

onvif protocol does not support motion detection recording

Model:N6200-16EH

• Desktop Installation, Mini II 1HDD(2,5 inches) NVR, Support 4T HDD(not include HDD);

• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR at any time and any place
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream, and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free

MINI NVR 8/16CH New 2017 Onvif P2P Cloud 960P/ 1080P mini 16CH NVR High Performance CCTV IP Camera Recorder 9Ch 3MP& 4Ch 5MP

Key Features

• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR

at any time and any place

• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based

on Onvif, RTSP standard

• Support megapixel HD network video preview, storage and playback;

• Support search, playback and backup by event;

• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream,

and 4 channels playback;

• Support monitor PTZ on preview mode

• Offer CMS for free

Main Functions

1. Preview channel can be switched to other channel randomly without changing the MAC which is convenient for

the project construction;

2. The dendritic menu can be moved. Man-machine communication is more direct and the settings of parameters

are more easy and convenient;

3. The mouse roller can realize 15X digital zooming which the enlarged image can be dragged and moved randomly

under preview and playback modes;

4. Immediate snapshot and immediate view; the picture will be stored in an independent area in the HDD;

5. The recording playback is shown by time bar and different color represents different recording type. It is very

fast and easy to find check the recording;

6. Recording backup can be accurate to second. Any time period of backup is available;

7. The recording files in the USB disk can play directly in the playback interface while the snapshot pictures can

be viewed directly;

8. Standard resolution which can be adjusted according to the display device in order to get the best image quality;

9. Adopt HDD sequence writing method and the data is written from 0 track which increase 2.5X lifetime of the HDD

Model Number

N6200-16EH

Operating System

Embedded LINUX operating system

Image Code Control

Image code quality adjustable, variable bitstream and constant bitstream optional

Dual Stream

Each channel can set main stream and sub stream

Video Standard

1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps

Monitoring Image Quality

1080P(1920×1080) / 960P/(1280×960)/720P(1280×720)

Image Motion Detection

Each screen can set multiple detection areas and set 6-level sensitivity

Recording Playback Quality

Any 9ch 960P playback, 4ch 5MP/3MP/1080P playback simultaneously

Region Cover

Every channel can set 4 cover regions(IPC Support)

Recording Mode

Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support)

Backup Way

Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup

Operation Way

Mouse, remote control, front panel

Local Login

User name and password

Recording Storage

Local HDD, network

External Ports

Video Input

16×(1920*1080)+sub[960*576]+4Ref.+4Play 16ch 2.0MP IP Camera

16×(1280*960)+sub[960*576]+4Ref.+9Play 16ch 1.3MP IP Camera

9×(2048*1536)+sub[960*576]+4Ref.+4Play 9ch 3.0MP IP Camera

4×(2592*1944)+sub[960*576]+4Ref.+4Play 4ch 5.0MP IP Camera

Audio Input

16/9ch network audio input

Video Output

1ch VGA+1ch HDMI

Network Port

1 RJ45,10M/100M/1000M self-adaptive LAN port

USB Port

2*USB 2.0 ports

HDD

HDD Port

1*2,5”HDD + 1*E-SATA HDD Port

MAX Capacity

Each port supports MAX 4TB HDD

Mobile Surveillance

Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone

Power Supply

5V2A

Power Consumption

≤10W(without HDD)

Working Temperature

-10C-+55C

Working Humidity

10%-90%

Dimension

Equipment:162mm×162mm×35mm ,Packing:210mm×210mm×60mm

Weight(without HDD)

N.W.:280g;With packing:700g

Outside Carton

20 pcs/carton. 215mm×215mm×610mm;Weight:7Kg

Installation Way

Desktop Installation

MINI NVR 8CH 1080P/960P/720P 1HDD PORT

Note: onvif protocol does not support motion detection recording

Model N6200-8EL

• Desktop Installation, Mini II 1HDD(2,5 inches) NVR, Support 4T HDD;
• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR at any time and any place
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream, and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free

Model Number

N6200-8EL

Operating System

Embedded LINUX operating system

Image Code Control

Image code quality adjustable, variable bitstream and constant bitstream optional

Dual Stream

Each channel can set main stream and sub stream

Video Standard

1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps

Monitoring Image Quality

1080P(1920×1080) / 960P/(1280×960)/720P(1280×720)

Image Motion Detection

Each screen can set multiple detection areas and set 6-level sensitivity

Recording Playback Quality

Any 9ch 960P playback, 4ch 5MP/3MP/1080P playback simultaneously

Region Cover

Every channel can set 4 cover regions IPC Support

Recording Mode

Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support)

Backup Way

Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup

Operation Way

Mouse, remote control, front panel

Local Login

User name and password

Recording Storage

Local HDD, network

External Ports

Video Input

8×(1280*720)+sub[640*360]+1Ref.+4Play 8ch 720P IP Camera

8×(1280*960)+sub[640*480]+4Ref.+1Play 8ch 960P IP Camera

8×(1920*1080)+sub[640*480]+2Ref.+1Play 8ch 1080P IP Camera

8×(1280*960)+sub[720*576]+2Ref.+1Play 8ch 960P IP Camera

8×(1920*1080)+sub[720*576]+1Ref.+1Play 8ch 1080P IP Camera

Audio Input

1ch network audio input

Video Output

1ch VGA+1ch HDMI

Network Port

1 RJ45,10M/100M/1000M self-adaptive LAN port

USB Port

2*USB 2.0 ports

HDD

HDD Port

1*2,5”HDD + 1*E-SATA HDD Port

MAX Capacity

Each port supports MAX 4TB HDD

Mobile Surveillance

Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone

Power Supply

5V2A

Power Consumption

≤10W without HDD

Working Temperature

-10~~+55

Working Humidity

10%-90%

Dimension

Equipment:162mm×162mm×35mm Packing: 210mm×210mm×60mm

Weight(without HDD)

N.W. 280gWith packing 700g

Installation Way

Desktop Installation
